» Floating Fenders » Foam Filled Fender » String Net Type Foam Filled Fender

String Net Type Foam Filled Fender

Product Name: String Net Type Foam Filled Fender

Product Type: Floating Fenders, Foam Filled Fenders

Key Words: String Net Type Foam Filled Fender, Floating Fender, Foam Fender, Foam Filled Fender

Enquiry
  • Description

String Net Type Foam Filled Fender Dimensions:

Diameter×Length Standard capacity fenders High capacity fenders
E at 60% Comp. (kNm) R at 60% Comp. (kN) Approx. Weight (kg) E at 60% Comp. (kNm) R at 60% Comp. (kN) Approx. Weight (kg)
300×500 18 19 6 3.8 54 7
400×800 7 40 7 9 72 8
300×1000 8 45 10 10 54 11
500×1000 9 48 38 12.6 75 41
600×1000 12.5 89 45 15.3 109 49
600×1000 15 107 50 18.3 131 55
700×1500 25.5 156 77 31 191 85
750×1500 29 167 80 36 204 89
900×1800 50.5 241 125 62 294 140
1000×1500 52 223 110 64 272 125
1000×2000 69.5 297 150 85 363 170
1200×2000 100 356 245 122 436 275
1200×2400 120 428 330 146 523 265
1250×2000 108 371 320 132 454 253
1250×2500 135 464 375 165 587 410
1500×3000 234 668 500 288 817 570
1500×4000 312 891 625 381 1089 720
1700×3000 300 757 610 367 926 700
1700×3500 350 883 675 428 1080 780
1800×3000 337 801 750 412 980 850
1800×3600 404 682 850 494 1176 965
2000×3000 416 891 840 508 1089 965
2000×3500 485 1039 950 593 1271 1100
2000×4000 554 1188 1050 678 1452 1220
2400×4000 799 1426 1475 976 1743 1720
2400×4800 958 1710 1850 1171 2091 2140
2500×4000 866 1485 1600 1069 1815 1885
2500×5000 1082 1856 2170 1324 2269 2500
2500×5500 1191 2041 2325 1456 2496 2675
2700×5400 1364 2165 2450 1668 2647 2865
3000×5000 1574 2249 2730 1924 2750 3200
3000×6000 1871 2672 3150 2287 3268 3740
3300×6500 2452 3184 4000 2998 3994 4735
3600×7200 3232 3848 4900 3953 4706 5800

String net type foam filled fender is manufactured with a foam core as all foam fenders. This fender type choose the manual string net as the outfit. It is an economical and portable combination. There is no formal standard for foam fenders to comply with, but its property of resistance and robustness has won world wide recognition.

Compared with pneumatic fenders, the foam fenders are much heavier and more inconvenient in storage and delivery. However, the foam fenders can remain high performance when damaged. Because of this particularity, this fender type is favored by naval applications for heavy duty. Besides the difference, the foam fenders and the pneumatic fenders share a common feature of proportional increase of energy absorption and reaction force under operation process.

Funciones:

  • Tough and robust for heavy duty
  • Stable performance even if damaged
  • Proportional increase of energy absorption and reaction force

Aplicaciones:

  • Heavy duty operations
  • Ship to shore operations with rough and uneven surface
