M type tugboat fender is another type of tugboat fenders. M type fenders, as well as W type tugboat fenders are installed on the bow and stern sections of the tugboat. The large and flexible contact area of this fender can minimize the pressure acting on the vessels during berthing operations. It’s size can be adjusted to fit for being installed on narrow curves. In this way, the fender can greatly protect vessels from damage during berthing operations.
M Type Tugboat Fender Drawing and Dimensions:
| Modelo |
A |
B |
C |
D |
E |
F |
| W240 |
240 |
100 |
25 |
20 |
23 |
95 |
| W240 |
240 |
120 |
35 |
13 |
33 |
30 |
| W400 |
400 |
200 |
40 |
23 |
50 |
150 |
| W500 |
500 |
250 |
50 |
27 |
60 |
190 |
| W600 |
600 |
300 |
60 |
33 |
70 |
230 |
| W800 |
800 |
400 |
80 |
44 |
95 |
305 |
| NOTA (unidades:milímetro) |
Other dimensions are available on request.
Instalación de M Type Tugboat Fenders:
M Type Tugboat Fenders In Factory:
Introducción:
M type tugboat fender has the same profile with M type rubber fender and similar profile with W type rubber fender and W type tugboat fender. They share the similar performance capability and applications. However, W type rubber fender and tugboat fender have two legs, on leg less than M type fenders(more information about W type fenders, please click W type rubber fender and W type tugboat fender). All of them are hot fender products in current market.
Accesorios y fijaciones:
- Bolts and nuts
- Mounting rod pins
- Washers
- Steel steel bar
